Heavy-Duty Industrial CPVC Butterfly Valve
Nikunj Fibre Glass is a leading manufacturer of the industrial CPVC Butterfly Valve in Vapi, Gujarat. Specifically, this wafer-style valve controls large-diameter flows in corrosive chemical pipelines. In fact, it provides compact lightweight construction and low operating torque. Moreover, our valves offer exceptional flow capacity from 2″ (50 mm) up to 12″ (300 mm) NB.
Key Engineering Advantages
- Universal Wafer Body Design: For example, the multi-standard flange pattern matches ANSI Class 150 standards. In addition, it connects seamlessly with DIN PN10/PN16 and BS10 flanges.
- Full-Boot Elastomeric Liner: Meanwhile, a heavy elastomer liner completely isolates the body and shaft from corrosive fluids. Consequently, pipeline installers do not require extra flange gaskets.
- Aerodynamic CPVC Disc Design: Additionally, the slim high-strength disc maximizes flow coefficients and minimizes pressure drop. Furthermore, it delivers outstanding erosion resistance during continuous throttling.
- Flexible Actuation Options: We supply a 10-position locking hand lever for quick quarter-turn control. Also, an industrial worm gearbox ensures smooth, non-slam operation on larger lines.
Technical Specifications
| Parameter | Specification Details |
|---|---|
| Valve Type | Wafer type concentric industrial butterfly valve |
| Size Range | 2″ (50 mm) to 12″ (300 mm) NB sizes |
| Body and Disc Material | Molded chlorinated polyvinyl chloride compound |
| Stem Material | Grade SS316 stainless steel shaft |
| Seat Liner Options | Heavy-duty EPDM or Viton FKM seals |
| Pressure Rating | PN10 rated for 10 bar or 150 PSI |
| Operating Temperature | Continuous duty up to 93°C (200°F) |
Ideal Applications
Undoubtedly, each CPVC Butterfly Valve excels across severe industrial fluid networks. For instance, plants install them on effluent treatment headers and chlor-alkali brine piping. In addition, chemical circulation loops and reverse osmosis systems benefit from their non-corrosive design. As a result, operations across Gujarat run safely with minimal downtime.
Ketan R. Mehta (verified owner) –
8-inch CPVC wafer butterfly valve installed in hot acidic effluent header. Hand-lever lock positions firmly and the liner doesn’t pinch or bind against the disc. Very reliable valve.
